Details

X-220 milling machine was developed byShenzhen Xiang Tong Medical Techology Co., LTD. Four axis dental carving and milling machine,integrated design, making work regionalization simplicity;Dry milling machine,especially the development of control system.Fitting with X-soform operation platform and supporting the use of digital denture;Horizontal structure design, the key control unit is made of high quality imported original, screw, guide rail, such as components and maintenance-free design, reducing the equipment for professional maintenance problems.High speed, high precision machining, wax takes3-4 min/pc, zirconium takes 8-10 min/pc. 2015 X-220 milling machine become China's best-selling dental CAD/CAM carving and milling,annual sales of more than 150 units, the total market more than 350 units, worthy of sales champion.

Dimension：730*720*620(mm)
Net Weight：Approximately 150kg
Input Voltage：Single-Phase 220V 50/60HZ
Max Power：2.0KW
Spindle Power:1.2kw
Axis quantity：4
Milling Range：XYZ：125/130/80mm A:360°
Milling Mode：Dry milling
Max speed：36，000rpm
Max feeding speed：6000mm/min
Bur Capacity：3
Bur Changing：Automatic
Cooling：water cooling
Materials：Zirconia、Wax、PMMA
Milling Time: zirconia：8 mins wax：3mins
